Air Balancing

Air balancing is a crucial step in HVAC commissioning. Each pressured air system needs to be balanced upon preliminary startup, and a few engineers or metropolis officers might demand it earlier than last approval. Nonetheless, in my private expertise, air balancing is barely requested when there’s a noticeable concern with system efficiency, often heat or chilly bedrooms, or a perceived lack of airflow. Regardless of the cause, an air balancing, achieved accurately, can alleviate these points, and assist make sure the tools is working as effectively as attainable.

Balancing might be achieved plenty of methods, however the next fundamental steps are frequent to most strategies.

1. Guarantee you’ve correct documentation.

   Earlier than a system might be balanced, the technician ought to have any related documentation out there to review and check with whereas balancing. This consists of, however not restricted to, duct design calculations, duct format, tools specs and management documentation. If these aren’t out there, then a sketch of the duct system needs to be made, in addition to a recording of any nameplate knowledge on the air handler. Make a chart to trace the airflows of every inlet and outlet, noting design airflows and leaving room to report precise airflows for comparability.
2. Affirm the system is working at design circumstances.

   As soon as the system is began up, be certain it’s working as near design parameters as attainable. Test to verify all quantity and splitter dampers are open. Ensure that the proper fan pace is engaged. Take a static stress studying or duct traverse, to make sure CFM and stress are inside design limits. Guarantee delta-T is throughout the acceptable vary. Ensure that any required equipment are in place, reminiscent of a filter.
3. File airflows at every provide outlet.

   Utilizing an airflow measuring software, measure the airflow at every outlet and inlet and report them. Ensure that to account for the grille elements (Ak) of every grille and register within the system. For residential retailers, reminiscent of a 4×10 flooring register, a vane anemometer is greatest. For business diffusers, reminiscent of a 24×24 cone diffuser, a circulation hood might have for use. Lookup producer’s engineering knowledge for Ak elements.
4. Modify department dampers as vital.

   Examine the design airflows to the measured airflows. Utilizing the balancing dampers put in in every department outlet, damper down the retailers with the very best airflow till they’re inside 10% of design. This may increasingly require some trial and error to search out the proper damper place.
5. Repeat steps 3 and 4 till all outlet airflows are inside 10% of design.

   As soon as the airflows are set, guarantee all dampers are safe. Make one final measurement at every outlet to report a last CFM worth. This may increasingly imply measuring every outlet a number of occasions.

Return air inlets might be balanced the identical means as above, however provided that they’re outfitted with balancing dampers. In Ontario, the present development is to make use of stud and joist areas as return air paths. They often don’t have any dampers put in and there’s no assure that the openings within the framing might be reduce to an sufficient measurement. In these instances, not a lot might be achieved to stability the return facet.

For extra data on system balancing procedures and strategies, I extremely advocate selecting up a replica of ACCA Handbook B Balancing and Testing Air and Hydronic Methods. It’s a useful software for any tech seeking to study extra about balancing methodology.

By Jason Rende
@rendenator_hvac
